VT6030-120

Electronic Neon Power Supply
Indoor Type 7

Features

  • Pull-chain on/off switch
  • Unit will not trip on capacitive currents up to 15mA
  • Line load regulated (30mA self-adjusting Output regardless of load size or input voltage fluctuations)
  • Sign grounding connection via mounting foot and plug
  • UL 2161 listed
  • 32″ GTO leads
  • Complies with CSA22.2, No. 107.1, No. 13
  • High power factor
  • Open circuit and overload will shut unit down
  • Ten-foot power cord (3 Pin)

Exclusive: These units are protected by Ventex’s patented protective circuitry to prevent false tripping due to capacitive current. Patent #5892646

2-Year Warranty

SPECS

Input Voltage (50/60Hz) 120VAC (+/-10%)
Input Current .06A rms max.
Power Factor 0.95
Output Frequency Variable
Output Voltage 0V-6,000V
Output Current 30mA
Operating Temperature 32°F to 104°F / 0°C to 40°C
Driving Distance* (Based on Stardard 12mm tube. Deduct one foot from driving footages for each pair of electrodes.)
Neon 3-16 ft (1-4.9 m)
Mercury 3-19 ft (1-5.8 m)

*See Ventex Luminous Tube Footage Chart for more information.

RESOURCES

Dimensions

Length (A) 6.50 in 16.5 cm
Width (B) 2.05 in 5.2 cm
Height (C) 1.45 in 3.7 cm
Mounting (D) 6.0 in 15.2 cm
Mounting (E) 1.03 in 2.6 cm
Weight 24.0 oz 680 g
Power Cord 10.0 ft 3.0 m
GTO Leads 32.0 in 81.3 cm
