VT9030D-120

Electronic Neon Power Supply
Indoor Type 7

Offers three levels of lighting: 100%, 75%, 50%

Features

  • 32” GTO leads
  • Pull-chain on/off switch
  • Unit will not trip on capacitive currents up to 15mA
  • Line load regulated (30mA self-adjusting Output regardless of load size or input voltage fluctuations)
  • Sign grounding connection via mounting foot
  • Ten-foot power cord (3 Pin)
  • UL 2161 listed
  • Complies with CSA22.2, No. 107.1, No. 13
  • High power factor
  • Special bulk with special 18 feet IEC Connector
  • Open circuit overload will shut unit down

NOTE: Under a fault condition, unit will attempt to reset two more times then latch off permanently unless the fault clears. Intermittent faults will not affect the operation of the unit.

2-Year Warranty

Specs

Input Voltage 120VAC (+/-10%) 50/60 Hz
Input Current 0.9A rms
Power Factor 0.95
Output Frequency Variable
Output Voltage 0V-9,000V
Output Current 30mA (3 Level Dimming*)
Operating Temperature 32°F to 104°F / 0°C to 40°C
Driving Distance* (Based on Standard 12mm tube. Deduct one foot from driving footages for each pair of electrodes.)
Neon 4-26 ft (1.2-7.9 m)
Mercury 4-31 ft (1.2-9.4 m)

*See Ventex Luminous Tube Footage Chart for more information.

Resources

Dimensions

Length (A) 6.50 in 16.5 cm
Width (B) 3.15 in 8.0 cm
Height (C) 1.55 in 3.9 cm
Mounting (D) 6.0 in 15.2 cm
Mounting (E) 2.25 in 5.7 cm
Weight 30 oz 850 g
Power Cord 10.0 ft 3.0 m
GTO Leads 32.0 in 81.3 cm
