VT9030-120

Electronic Neon Power Supply
Indoor Type 7

Features

  • Pull-chain on/off switch
  • 10-foot power cord (3 Pin)
  • Unit will not trip on capacitive currents up to 15mA
  • Line load regulated (30mA self-adjusting Output regardless of load size or input voltage fluctuations)
  • Sign grounding connection via mounting foot
  • UL 2161 listed
  • Complies with CSA22.2, No. 107.1, No. 13
  • High power factor
  • Open circuit overload and ground fault protection

Exclusive: These units are protected by Ventex’s patented protective circuitry to prevent false tripping due to capacitive current. Patent #5892646

2-Year Warranty

Specs

Input Voltage (50/60Hz) 120VAC (+/-10%)
Input Current 0.9A rms
Power Factor 0.95
Output Frequency Variable
Output Voltage 0V-9,000V
Output Current 30mA
Operating Temp 32°F to 104°F / 0°C to 40°C
Driving Distance** (Based on Standard 12mm tube. Deduct one foot from driving footages for additional pair of electrodes.)
Neon 4-26 ft (1.2-7.9 m)
Mercury 4-31 ft (1.2-9.5 m)

**See Ventex Luminous Tube Footage Chart for more information.

Resources

Dimensions

Length (A) 6.50 in 16.5 cm
Width (B) 3.15 in 8.0 cm
Height (C) 1.55 in 3.9 cm
Mounting (D) 6.0 in 15.2 cm
Mounting (E) 2.25 in 5.7 cm
Weight 29.0 oz 822 g
Power Cord 10.0 ft 3.0 m
GTO Leads 32.0 in 81.3 cm
